Specification
● Seidentopf Trinocular Head: Inclined 45°, interpupilary distance: 48-76mm, Light distribution (both): 100: 0 (100% for eyepiece), 80:20 (80% for trinocular head, and 20% for eyepiece)
● Eyepiece: HWF 10X/22mm (adjustable)
● Infinity Plan Achromatic Objectives for Long Working Distance:
- L Plan FL 10X/0.25 W.D.=10.3mm
- L Plan FL 20X/0.45 W.D.=5.8mm
- L Plan FL 40X/0.65 W.D.=5.1mm
● Infinity Plan Phase Contrast Objectives:
- L Plan FL PHP 10X/0.25 W.D.=10.3mm
● Annular Spot: 10X/20X/40X
● Nosepiece: Quintuple
● Mechanical Stage:
- Stage size: X×Y 210×241mm, Round slide size: φ110mm
- Attached mechanical stage (available for 96 holes plate, moving range X×Y: 128×80mm)
● Culture/Petri Dish Holder: 54mm
● Condenser: Long working distance, Quickly detachable, N.A.0.3, Working distance: 72mm (with condenser), 195mm(without condenser)
● Koehler illumination: 6V/30W Halogen, input voltage: 100V~240V
● Filter: Blue(φ34), Green(φ34)
● Power: 100-240VAC 50/60Hz
Packing list
1x Microscope body
1x Pair HWF 10X/22mm eyepieces
1x Infinity plan achromatic objectives: 10X/ 20X/ 40X
1x Infinity plan Phase contrast objectives: 10X
1x Annular spot: 10X/20X/40X
1x Culture dish holder
1x Condenser
1x Blue, Green filter
1x Power Cord
1x Dust cover
Note
Need other optional accessories, please send a quotation to us!
